LS-201 Gemstone Shaping Machine
The stone would fix with a clamp, clamp always rotating when the machine working, the rotating speed adjust by the stone hardness, we suggest start with slow speed for preshaping.
This model max cutting stone width 50-60 mm.
With water recycle system.
LS-201 Gemstone Shaping Machine
Lotustep Gem Shaping Machine works with a diamond shaping wheel, it can make stone into different shapes such as round bead, flat bead, cylinder, egg, heart, wands, round cab and oval cab, comes out stone pieces with uniform shape and precise size.
The stone would fix with a clamp, clamp always rotating when the machine working, the rotating speed adjust by the stone hardness, we suggest start with slow speed for preshaping.
This model max cutting stone width 50-60 mm.
With water recycle system, comes with a pump.
Used for different hardness stone, like jade, agate, crystal, quartz, shell, turquoise and fossi, we suggest diamond grit 60/80 for very hard stone like agate and quartz, grit 180/220 for soft stone like amber and turquoise.
First choice for gemstone mass production with uniform shape and precise size, one machine can produce 1000-2500 pcs stone pieces for 8 hours.
Specification of LS-201
Voltage:220/380 V
Power:0.75 KW(1 HP)
Speed of shaping wheel:2880 RPM
Speed of stone clamp:0-200 RPM
Max cutting size:50 mm
Overall Size:L56*W52*H115 cm
Diamond Wheels to use
Sample Show
You need to remove the extra dot manually after the machine shaping
